The Submersible Ceramic Level Sensor is a liquid level measuring instrument with high stability and precision. It adopts fully sealed 316SS stainless steel body and ceramic core body, high explosion-proof and easy to clean.
Application :
● Water level measure
● Corrosive liquid level measurement
● Level measurement in telecom base station
● Oil level measurement
Advantages
- Surge protection from lightning strikes and voltage spikes
- Ceramic pressure cell resistant to 10x burst pressure
- Rugged design: Ingress protection up to IP 68
- Lightning (Surge) Protection
- Excellent Long Term Stability
- CE/ATEX Certificate approved
Technical Data
| Range | 0~1 M…200 M H2O optional |
| Output | 4~20mA;0-10V/0.5-4.5V;4-20mA HART;RS485 RTU Modbus |
| Temperature output | 4~20mA or resistance signal; Range: -10…100 degree C |
| Accuracy | 0.1%F.S;0.15%F.S;0.25%F.S optional |
| Working temperature | -20°C~+80°C |
| Temp Compensation | 0°C~70°C |
| Power supply | 12VDC~36VDC |
| Medium Compatible | 316L Flush diaphragm ,316 SST,Titanium Alloy |
| Process connection | Flange or throw-in type |
| Zero Temp. Drift | 0.03%FS/°C（≤100kPa）; 0.02%FS/°C（>100kPa） |
| FS Temp. Drift | 0.003%FS/°C（≤100kPa）; 0.002%FS/°C（>100kPa） |
| Certificate | CE,ExiaII CT6 Ga ,ATEX,RoHS |
| Application | Corrosive medium |
Order information
Level range : 0-0.5m , Output : 4-20mA , Power supply : 12~36VDC 1m directly cable : IP68
